F4U Corsair ARF set of EPP range of 1700 mm with an AC motor with controller 85A, 10 mounted servos and electric retractable landing gear. Controlled ailerons, rudder, elevator and flaps, functional marker lights. For 6S LiPo 3300-4000mAh.
Vought F-4U Corsair was the most powerful American airborne fighter aircraft of World War II. After solving the initial problem (too stiff chassis and poor visibility complicated the landing on aircraft carriers) along with the Grumman Hellcat care of wiping out the Japanese air force from the skies over the Pacific. Corsair successfully operated and vbarvách British Fleet Air Arm and land airports in squads Marine Corps. In service with the U.S. Navy and Marines endured well into the 50th years, when the fighter-bomber role contributed significantly to capture the initial onslaught of communist North Korea at the beginning of the Korean War ..
1400 mm EPP models are already "old hat" ... well, we'll have something even bigger - a proper maritime Mack - F4U Corsair with a span of 1700 mm! Put in a given FMS depend on the amount Scale Detail (including functional position lights) and overall realistic design with retractable landing gear (including spur) and flaps - that is, my, thing! Veeelkééé size, attractive appearance "warbird" a good flight characteristics make EPP Giant Corsair monstrous role in recreation fighters seasoned warrior pleasant dose of epinephrine for an experienced pilot who reliably handles flying fast aerobatic models ...
The fuselage of EPP foam comes fitted with a brushless motor with rotating case (C5060-300) with fitted SBEC 85 A AC regulator and the switched power stabilizer UBEC 6/10 A to power the receiver and servos. To simplify the on-board electrical wiring harnesses are two multiconnectors merging with electronics in half wings and fuselage, also provide positional power LED lights from the receiver. For connection to the receiver are connected servokonektory standard JR / UNI pretty clearly marked with flags with the channel number (standard channel order Hitec / Futaba). Easy access to the receiver and the propulsion battery guarantees a removable canopy. S model comes to scale four-bladed propeller.
The wing also made of EPP foam with polosouměrným profile is a two-piece, jointed 2 trubkovovými fiberglass couplings. The hull is fitted bottom four screws. The ailerons and flaps are controlled by two miniservo with metal gears placed in the wing.
The horizontal tail and vertical tail of EPP is fixed with screws to the body. The tail surfaces are controlled miniservo with metal gears placed in the cabin by means of wire rods.
Before connecting rods recommend the helm of "motion" repeated careful deflecting up and down respectively. left and right.
The chassis is plastic with electric retractable door closing by a otvíranými special servos, spur is controlled by a separate servo. Coordination of movement undercarriage legs and doors provides an electronic sequencer supplied in the kit.
For model, you need Li-poly šestičlánek 3300 - 4000 mAh with a load capacity of at least 25C.
To control the model you need at least a six-channel RC set. When connecting the receiver, refer to the instruction manual of your RC kit. Controlled by the ailerons, flaps, rudder, elevator and motor speed.
ARF set contains nearly finished model with brushless motor, a four-blade propeller, speed controller, 10 servos, electric retractable landing gear, LED position lights, accessory kit, contact adhesive EPP, image guidance.
Size [mm] 1700
Length [mm] 1380
Weight [g] 4700
Wing Area [dm2] 54.7
Controlled functions S, V, K (2), M, P (3), F (2)
Building intensity of S2
Difficulty piloting P3
Drive and RC equipment:
Black Sheep
Motor * C5060-300
Controller * AC 85A SBEC
Propeller * 16 "čtyřílistá
Battery 2x G3 RAY 11.1 V 3250 mAh
Servos * 6x Mini MG 25 grams, 17 grams 1x mic, 3x micro 9 g
RC kit min. 6 channels
*) Part of the ARF set
